12-bit, 16-channel Analog-to-Digital Converter (ADC) with a 1MSPS sampling rate. Features single-ended input, SPI serial interface, and a 2LSB full-scale error. Operates from a 2.7V to 5.25V supply, with a maximum power dissipation of 12.5mW. Packaged in a 28-lead TSSOP for surface mounting, this unipolar ADC offers 69.5dB signal-to-noise ratio and is RoHS compliant.
PackageTSSOP
MountingSurface Mount
PolarityUnipolar
Power12.5mW
Quick Jump:
Technical Specifications
Analog Devices AD7490BRUZ-REEL7 technical specifications.
General
Package/Case
TSSOP
Contact Plating
Tin, Matte
Differential Nonlinearity
-0.95LSB
Full Scale Error
2LSB
Input Type
SINGLE-ENDED
Integral Nonlinearity (INL)
1LSB
Interface
SPI, Serial
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
12.5mW
Max Supply Voltage
5.25V
Min Supply Voltage
2.7V
Mount
Surface Mount
Number of A/D Converters
1
Number of Analog Inputs
16
Number of Bits
12
Number of Channels
16
Number of Converters
1
Number of Elements
1
Number of Inputs
16
Package Quantity
1
Packaging
Tape and Reel
Polarity
Unipolar
Power Dissipation
12.5mW
Radiation Hardening
No
Resolution
12b
RoHS Compliant
Yes
Sampling Rate
1MS/s
Signal to Noise Ratio (SNR)
69.5dB
Supply Type
Single, Analog, Digital
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD7490BRUZ-REEL7 Datasheet
Download the complete datasheet for Analog Devices AD7490BRUZ-REEL7 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
