100MHz to 2.5GHz logarithmic detector/controller with 70dB dynamic range. Features 8 elements, 84dB voltage gain, and a 40ns response time. Operates from a 2.7V to 5.5V supply with 13.7mA nominal current. Housed in an MSOP package for surface mounting, this component offers a 900 Ohm input resistance and 10uA input bias current.
Frequency100MHz
PackageMSOP
MountingSurface Mount
Power200mW
Quick Jump:
Technical Specifications
Analog Devices AD8313ARMZ-REEL7 technical specifications.
General
| Package/Case | MSOP |
| Frequency | 100MHz |
| Input Bias Current | 10uA |
| Input Resistance | 900R |
| Lead Free | Contains Lead |
| Length | 3mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 200mW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Nominal Supply Current | 14mA |
| Number of Channels | 1 |
| Number of Elements | 8 |
| Operating Supply Current | 13.7mA |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| Power Dissipation | 200mW |
| Radiation Hardening | No |
| Response Time | 40ns |
| RoHS Compliant | Yes |
| Voltage Gain | 84dB |
| Weight | 0.004938oz |
| Width | 3mm |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices AD8313ARMZ-REEL7 Datasheet
Download the complete datasheet for Analog Devices AD8313ARMZ-REEL7 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
