Differential RF/IF Amplifier with 2.2GHz -3dB Bandwidth and 2.2GHz Gain Bandwidth Product. Features 26dB gain, 13.5dBm P1dB, and a 15.5dB noise figure. Operates from a 3V to 5.5V supply with 28mA typical current. Housed in an MSOP package for surface mounting, this component offers a 13000V/µs slew rate and a maximum power dissipation of 320mW.
PackageMSOP
MountingSurface Mount
Power320mW
Quick Jump:
Technical Specifications
Analog Devices AD8351ARMZ-REEL7 technical specifications.
General
-3db Bandwidth
2.2GHz
Package/Case
MSOP
Gain
26dB
Gain Bandwidth Product
2.2GHz
Lead Free
Contains Lead
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
320mW
Max Supply Voltage
5.5V
Min Supply Voltage
3V
Mount
Surface Mount
Noise Figure
15.5dB
Number of Channels
1
Operating Supply Current
28mA
Operating Supply Voltage
5.5V
P1dB
13.5dBm
Package Quantity
1000
Packaging
Tape and Reel
Power Dissipation
320mW
Radiation Hardening
No
RoHS Compliant
Yes
Slew Rate
13000V/µs
Test Frequency
10MHz
Compliance
RoHS
Compliant
Datasheet
Analog Devices AD8351ARMZ-REEL7 Datasheet
Download the complete datasheet for Analog Devices AD8351ARMZ-REEL7 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
