Dual-channel ultrafast comparator with a 5ns response time and 4ns propagation delay. Features a 3V to 5V supply voltage range, 10mA output current per channel, and TTL output compatibility. Operates across a -40°C to 85°C temperature range with 85dB CMRR and 73dB PSRR. Packaged in a 14-lead TSSOP with tin/matte contact plating.
PackageTSSOP
Current10mA
Power100mW
Quick Jump:
Technical Specifications
Analog Devices AD8612ARUZ technical specifications.
General
Package/Case
TSSOP
Common Mode Rejection Ratio
85dB
Contact Plating
Tin, Matte
Height
1mm
Input Bias Current
6uA
Input Offset Voltage (Vos)
7mV
Lead Free
Contains Lead
Length
5mm
Max Input Current
6uA
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
100mW
Max Supply Current
10mA
Max Supply Voltage
5V
Min Supply Voltage
3V
Number of Channels
2
Number of Elements
2
Output Compatibility
TTL
Output Current per Channel
10mA
Output Type
TTL
Package Quantity
96
Packaging
Rail/Tube
Power Dissipation
100mW
Power Supply Rejection Ratio (PSRR)
73dB
Propagation Delay
5.5ns
Quiescent Current
4mA
Radiation Hardening
No
Reach SVHC Compliant
No
Response Time
5ns
RoHS Compliant
Yes
Supply Current
10mA
Technology
BIPOLAR
Voltage Gain
69.54dB
Width
4.4mm
Compliance
RoHS
Compliant
