Integrated Synthesizer and VCO, a single-circuit RF & Wireless IC designed for cellular applications. Features a PLL with three outputs, operating from a 3V to 3.6V supply range with a nominal current of 38mA. Achieves a maximum frequency of 1.8GHz, with operating temperatures from -40°C to 85°C. Packaged in LFCSP EP for surface mounting, supplied on tape and reel.
Frequency1.8GHz
PackageLFCSP EP
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices ADF4360-7BCPZRL7 technical specifications.
General
| Package/Case | LFCSP EP |
| Input | CMOS |
| Lead Free | Contains Lead |
| Max Frequency | 1.8GHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 3V |
| Mount | Surface Mount |
| Nominal Supply Current | 38mA |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Outputs | 3 |
| Operating Supply Current | 45mA |
| Operating Supply Voltage | 3.3V |
| Packaging | Tape and Reel |
| PLL | Yes |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
