High-performance FSK/ASK transceiver IC supporting a frequency range of 135MHz to 650MHz. Features a data rate of 200Kbps and a maximum output power of 13dBm. Operates with a supply voltage between 2.3V and 3.6V, drawing a nominal current of 27mA. Includes a serial 3-wire SPI interface and a sensitivity of -119.2dBm. Packaged in an LFCSP EP with tin-matte contact plating, suitable for surface mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices ADF7020-1BCPZ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices ADF7020-1BCPZ technical specifications.
| Package/Case | LFCSP EP |
| Contact Plating | Tin, Matte |
| Current - Receiving | 20.1mA |
| Current - Transmitting | 21mA |
| Data Rate | 200Kbps |
| Depth | 7mm |
| Frequency | 650MHz |
| Height | 0.83mm |
| Interface | Serial, 3-WIRE, SPI |
| Lead Free | Contains Lead |
| Length | 7mm |
| Max Frequency | 650MHz |
| Min Frequency | 135MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 2.3V |
| Mount | Surface Mount |
| Nominal Supply Current | 27mA |
| Number of Drivers | 1 |
| Number of Receivers | 1 |
| Number of Transceivers | 1 |
| Operating Supply Current | 21mA |
| Operating Supply Voltage | 3.6V |
| Output Power (dBm) | 13dBm |
| Package Quantity | 1 |
| Packaging | Tray |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Sensitivity | -119.2dBm |
| Termination | SMD/SMT |
| Width | 7mm |
| RoHS | Compliant |
