Fault-protected analog multiplexer featuring 8 analog inputs and 2 outputs, with a 4PST throw configuration. Operates with a dual supply voltage of ±15V, up to ±22V, and a single supply voltage range of 10.8V to 16.5V. Offers a low drain-to-source resistance of 300Ω and a maximum power dissipation of 3.3mW. Packaged in a 48-piece rail/tube with a compact 10mm x 4mm x 1.5mm footprint.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices ADG509FBRNZ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | R |
| Drain to Source Resistance | 300R |
| Dual Supply Voltage | 15V |
| Height | 1.5mm |
| Interface | Parallel |
| Lead Free | Contains Lead |
| Length | 10mm |
| Max Dual Supply Voltage | 22V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 3.3mW |
| Max Supply Current | 1uA |
| Max Supply Voltage | 16.5V |
| Min Supply Voltage | 10.8V |
| Number of Channels | 1 |
| Number of Circuits | 2 |
| Number of Inputs | 8 |
| Number of Outputs | 2 |
| Operating Supply Voltage | 15V |
| Package Quantity | 48 |
| Packaging | Rail/Tube |
| Power Dissipation | 3mW |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Throw Configuration | 4PST |
| Width | 4mm |
| RoHS | Compliant |
Download the complete datasheet for Analog Devices ADG509FBRNZ to view detailed technical specifications.
