The ADN2530YCPZ-WP is a single-channel interface IC with a maximum operating temperature of 100°C and a minimum operating temperature of -40°C. It is designed for surface mount applications and operates at a nominal supply current of 65mA. The device is RoHS compliant and contains lead, making it suitable for lead-free applications. It is packaged in a tray and has a data rate of 11.3Gbps.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices ADN2530YCPZ-WP datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices ADN2530YCPZ-WP technical specifications.
| Data Rate | 11.3Gbps |
| Lead Free | Contains Lead |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Nominal Supply Current | 65mA |
| Number of Channels | 1 |
| Operating Supply Current | 65mA |
| Operating Supply Voltage | 3.3V |
| Packaging | Tray |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| RoHS | Compliant |
Download the complete datasheet for Analog Devices ADN2530YCPZ-WP to view detailed technical specifications.
