The ADP5034ACPZ-2-R7 is a 4-output DC/DC controller from Analog Devices, packaged in a Lead-Free LFCSP EP package. It operates over a temperature range of -40°C to 125°C and is RoHS compliant. The device can supply up to 1.2kA of current and has a maximum input voltage of 5.5V. The outputs are rated for 3.8V, 3.8V, 4.75V, and a minimum of 800mV, with a maximum output current of 1.2A for the first two outputs and 300mA for the third output.
PackageLFCSP EP
Quick Jump:
Technical Specifications
Analog Devices ADP5034ACPZ-2-R7 technical specifications.
General
| Package/Case | LFCSP EP |
| Current - Output 1 | 1.2A |
| Current - Output 2 | 1.2A |
| Current - Output 3 | 300mA |
| Lead Free | Contains Lead |
| Max Input Voltage | 5.5V |
| Min Input Voltage | 2.3V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 1.2kA |
| Max Output Voltage | 4.75V |
| Min Output Voltage | 800mV |
| Number of Outputs | 4 |
| Operating Supply Voltage | 5.5V |
| Package Quantity | 1500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Voltage - Output 1 | 3.8V |
| Voltage - Output 2 | 3.8V |
| Voltage - Output 3 | 4.75V |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices ADP5034ACPZ-2-R7 Datasheet
Download the complete datasheet for Analog Devices ADP5034ACPZ-2-R7 to view detailed technical specifications.
