PackageR
Current500uA
Quick Jump:
Technical Specifications
Analog Devices ADR421BR technical specifications.
General
Package/Case
R
Height
1.5mm
Lead Free
Contains Lead
Length
5mm
Max Input Voltage
18V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
10mA
Max Output Voltage
2.5V
Min Output Voltage
2.5V
Operating Supply Current
500uA
Output Current
10mA
Output Type
Fixed
Output Voltage
2.5V
Package Quantity
98
Packaging
Rail/Tube
Radiation Hardening
No
Reference Type
Series
RoHS Compliant
No
Series
XFET®
Supply Current
500uA
Tolerance
0.04%
Width
4mm
Compliance
RoHS
Not CompliantNo
Datasheet
Analog Devices ADR421BR Datasheet
Download the complete datasheet for Analog Devices ADR421BR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
