16-bit Digital Signal Processor (DSP) operating at 66MHz, featuring 192KB of RAM and a 2.5V supply voltage. This surface-mount IC offers dual serial ports and a host port for versatile connectivity. It operates within a temperature range of -40°C to 85°C and is housed in an LQFP package with tin-matte contact plating.
Frequency75MHz
PackageLQFP
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices ADSP-2189MBSTZ-266 technical specifications.
General
| Package/Case | LQFP |
| Contact Plating | Tin, Matte |
| Data Bus Width | 16b |
| Frequency | 75MHz |
| Height | 1.4mm |
| Interface | Serial |
| Lead Free | Contains Lead |
| Length | 14mm |
| Max Frequency | 66MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Type | RAM, |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.25V |
| Mount | Surface Mount |
| Number of Bits | 16 |
| Number of Timers/Counters | 1 |
| Operating Supply Voltage | 2.5V |
| Package Quantity | 90 |
| Packaging | Tray |
| Radiation Hardening | No |
| RAM Size | 192KB |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | ADSP-21xx |
| Width | 14mm |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices ADSP-2189MBSTZ-266 Datasheet
Download the complete datasheet for Analog Devices ADSP-2189MBSTZ-266 to view detailed technical specifications.
