Dual-channel digital isolator featuring 2.5kV isolation voltage and 25Mbps data rate. This general-purpose interface IC offers unidirectional channel type with two channels and one input line. Operating across a -40°C to 125°C temperature range, it supports supply voltages from 2.7V to 5.5V. The component is housed in a 5mm x 4mm x 1.5mm package with tin, matte contact plating.
PackageR
Current600uA
Quick Jump:
Technical Specifications
Analog Devices ADUM1201CRZ technical specifications.
General
Package/Case
R
Channel Type
Unidirectional
Contact Plating
Tin, Matte
Data Rate
25Mbps
Depth
1.5mm
Isolated Power
No
Isolation Voltage
2.5kV
Lead Free
Contains Lead
Length
5mm
Max Input Current
10uA
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
2.7V
Number of Channels
2
Number of Input Lines
1
Output Current
35mA
Package Quantity
98
Packaging
Rail/Tube
Propagation Delay
45ns
Pulse Width Distortion (PWD)
3ns
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
iCoupler®
Supply Current
600uA
Type
General Purpose
Width
4mm
Compliance
RoHS
Compliant
