Adjustable 2A DC-DC buck controller IC with a 3V to 36V input voltage range and a maximum output voltage of 20V. Features a 2A maximum output current and a minimum output voltage of 1.265V. Housed in a compact 10-MSOP package with dimensions of 3mm (L) x 3mm (W) x 0.86mm (H). Operates across a wide temperature range of -40°C to 85°C. This RoHS compliant component offers a single adjustable output.
PackageMSOP
Quick Jump:
Technical Specifications
Analog Devices LT3684EMSE#PBF technical specifications.
General
Package/Case
MSOP
Height
0.86mm
Lead Free
Lead Free
Length
3mm
Max Input Voltage
36V
Min Input Voltage
3V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Output Current
2A
Max Output Voltage
20V
Min Output Voltage
1.265V
Number of Outputs
1
Output Current
2A
Output Type
Adjustable
Output Voltage
20V
Package Quantity
50
Packaging
Rail/Tube
Reach SVHC Compliant
No
RoHS Compliant
Yes
Synchronous Rectifier
No
Width
3mm
Compliance
RoHS
Compliant
Datasheet
Analog Devices LT3684EMSE#PBF Datasheet
Download the complete datasheet for Analog Devices LT3684EMSE#PBF to view detailed technical specifications.
