The LTC2378CMS-18#PBF is a single-channel analog-to-digital converter with 18-bit resolution and a maximum sampling rate of 1,000,000 samples per second. It operates over a temperature range of 0°C to 70°C and is available in an MSOP package. The device is RoHS compliant and has a maximum power dissipation of 15.8 milliwatts. It can be supplied with a voltage between 2.375V and 2.625V.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices LTC2378CMS-18#PBF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices LTC2378CMS-18#PBF technical specifications.
| Package/Case | MSOP |
| Interface | SPI, Serial |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 15.8mW |
| Max Supply Voltage | 2.625V |
| Min Supply Voltage | 2.375V |
| Mount | Surface Mount |
| Number of Bits | 18 |
| Number of Converters | 1 |
| Package Quantity | 37 |
| Packaging | Rail/Tube |
| Reach SVHC Compliant | No |
| Resolution | 18b |
| RoHS Compliant | Yes |
| Sampling Rate | 1000000S/s |
| Supply Type | Analog, Digital |
| RoHS | Compliant |
Download the complete datasheet for Analog Devices LTC2378CMS-18#PBF to view detailed technical specifications.
