High-performance DC/DC buck controller IC for efficient power management. Features a wide input voltage range from 6.2V to 100V and supports a single output with up to 10A current and 55.8V output voltage. Operates at a maximum frequency of 1MHz with a broad operating temperature range of -40°C to 125°C. Surface mountable in a 28-pin SSOP package, this RoHS compliant component is ideal for demanding power applications.
Frequency1MHz
PackageSSOP
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices LTC3810EG#PBF technical specifications.
General
| Package/Case | SSOP |
| Max Frequency | 1MHz |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 100V |
| Min Supply Voltage | 6.2V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Current | 10A |
| Output Voltage | 55.8V |
| Package Quantity | 47 |
| Packaging | Rail/Tube |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Analog Devices LTC3810EG#PBF Datasheet
Download the complete datasheet for Analog Devices LTC3810EG#PBF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
