General purpose delay block IC featuring a single timer, ideal for surface mount applications. Operates within a 2.25V to 5.5V supply voltage range, with a maximum operating temperature of 70°C. Housed in a compact TSOT package measuring 2.9mm (L) x 1.75mm (W) x 1mm (H). This RoHS compliant component is supplied on tape and reel.
PackageTSOT
MountingSurface Mount
Quick Jump:
Technical Specifications
Analog Devices LTC6994CS6-1#TRMPBF technical specifications.
General
Package/Case
TSOT
Height
1mm
Length
2.9mm
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
5.5V
Min Supply Voltage
2.25V
Mount
Surface Mount
Number of Timers/Counters
1
Package Quantity
1
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
TimerBlox®
Width
1.75mm
Compliance
RoHS
Compliant
Datasheet
Analog Devices LTC6994CS6-1#TRMPBF Datasheet
Download the complete datasheet for Analog Devices LTC6994CS6-1#TRMPBF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
