Digital serial relative humidity sensor with 12-bit resolution, featuring a 1-Wire interface and PWM output. Operates from a 3V to 5.5V supply, consuming 425µA typical supply current. Encased in a compact 2.2mm x 1.35mm x 1mm SC package, suitable for surface-mount applications. Supports a wide operating temperature range from -40°C to 150°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Analog Devices TMP05AKSZ-500RL7 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Analog Devices TMP05AKSZ-500RL7 technical specifications.
| Package/Case | SC |
| Height | 1mm |
| Interface | PWM |
| Lead Free | Contains Lead |
| Length | 2.2mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 3V |
| Number of Bits | 12 |
| Number of Channels | 1 |
| Operating Supply Current | 650uA |
| Output Current | 10mA |
| Output Type | Digital |
| Package Quantity | 500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Supply Current | 425uA |
| Termination | SMD/SMT |
| Width | 1.35mm |
| RoHS | Compliant |
