Illuminated pushbutton switch, SPST, Off-(on) momentary function, featuring a red flush round brass actuator. This panel-mount switch offers a 50mA current rating at 24VDC, with gold-plated brass and gold contacts for reliable performance. It boasts an electrical life of 1,000,000 cycles and a mechanical life of 100,000 cycles, operating within a temperature range of -30°C to 70°C. The switch is IP54 rated for water resistance and includes red and yellow LED illumination.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Apem AV09C7L3D2006 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Apem AV09C7L3D2006 technical specifications.
| Actuator Length | 0mm |
| Actuator Material | Brass |
| Actuator Type | Round, Button, Flush |
| Color | Red |
| Contact Current Rating | 50mA |
| Contact Material | Gold, Brass |
| Contact Plating | Gold |
| Contact Type | 1 change-over |
| Current Rating | 50mA |
| Electrical Life | 1000000Cycles |
| Flammability Rating | UL94 V-0 |
| Illumination Color | Red, Yellow |
| Illumination Type | LED |
| Lead Free | Lead Free |
| Material | Metal |
| Max Operating Temperature | 70°C |
| Mechanical Life | 100000Cycles |
| Min Operating Temperature | -30°C |
| Max Voltage Rating (DC) | 24V |
| Mount | Panel, Front |
| Orientation | Straight |
| Package Quantity | 40 |
| Packaging | Bulk |
| Ratings | IP54, Water Resistant |
| RoHS Compliant | Yes |
| Series | AV |
| Switch Function | Off-Mom |
| Termination | Solder |
| Throw Configuration | SPST |
| DC Rated Voltage | 24V |
| RoHS | Compliant |
