Package200
Current Rating200mA
MountingPanel, Front
Quick Jump:
Technical Specifications
Apem PBAR1AF0000 technical specifications.
General
Actuator Type
Round, Button, Flush
Package/Case
200
Contact Current Rating
200mA
Contact Type
1 maker
Current Rating
200mA
Electrical Life
50000000Cycles
Material
Metal
Max Operating Temperature
75°C
Min Operating Temperature
-40°C
Mount
Panel, Front
Package Quantity
20
Packaging
Bulk
Ratings
IP68, Waterproof, Dust Tight, IP69K
RoHS Compliant
Yes
Series
PBA
Switch Function
Off-Mom
Switching Voltage
24V
Termination
Wire Leads
Throw Configuration
SPST
Voltage Rating (AC)
24V
DC Rated Voltage
24V
Compliance
RoHS
Compliant
Datasheet
Apem PBAR1AF0000 Datasheet
Download the complete datasheet for Apem PBAR1AF0000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
