The 5MT2-R PTC resettable fuse from BEL is a surface mount device with a current rating of 2A and a voltage rating of 250V. It has a maximum operating temperature of 125°C and a minimum operating temperature of -55°C. The fuse is lead free and RoHS compliant, making it suitable for use in a variety of applications. It has a power dissipation of 590mW and a length of 20mm, with a diameter of 5.1mm. The fuse is packaged in bulk and features nickel contact plating.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the BEL 5MT2-R datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Contact Plating | Nickel |
| Current Rating | 2A |
| DC Cold Resistance | 55mR |
| Diameter | 5.1mm |
| Lead Free | Lead Free |
| Length | 20mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Holder, Surface Mount |
| Packaging | Bulk |
| Power Dissipation | 590mW |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | 5MT |
| Voltage Rating | 250V |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 250V |
| RoHS | Compliant |
Download the complete datasheet for BEL 5MT2-R to view detailed technical specifications.
