3-pole, 2-electrode gas discharge tube for circuit protection. Features 90VDC breakdown voltage, 10kA peak pulse current, and 10A AC current handling. Offers 2pF capacitance with a 3.3mm lead pitch. Surface mountable in an SMD/SMT package, operating from -55°C to 85°C. RoHS compliant and lead-free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Bourns 2036-09-SM-RPLF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL |
| Capacitance | 2pF |
| Package/Case | SMD/SMT |
| Depth | 5mm |
| Fail Short | No |
| Height | 5mm |
| Lead Free | Lead Free |
| Lead Pitch | 3.3mm |
| Length | 7.3mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Poles | 3 |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 20kA |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 2036 |
| Termination | SMD/SMT |
| Tolerance | 20% |
| RoHS | Compliant |
Download the complete datasheet for Bourns 2036-09-SM-RPLF to view detailed technical specifications.
