Isolated resistor network, SIP package, featuring thick film technology for 10kΩ resistance with a 2% tolerance. This component offers a 100V DC rating and 300mW power per element, operating across a -55°C to 125°C temperature range. Designed for through-hole mounting with a 2.54mm terminal pitch, it provides 4 isolated elements within an 8-pin SIP package.
PackageSIP
Resistance10kR
Voltage Rating100V
MountingThrough Hole
Quick Jump:
Technical Specifications
Bourns 4308R-102-103LF technical specifications.
General
Package/Case
SIP
Circuit Type
Isolated
Contact Plating
Tin
Depth
2.16mm
Height
0.195inch
Lead Free
Lead Free
Length
19.92mm
Max Operating Temperature
125°C
Military Standard
Not
Min Operating Temperature
-55°C
Mount
Through Hole
Number of Contacts
8
Number of Elements
4
Number of Resistors
4
Package Quantity
25
Packaging
Bulk
Power Per Element
300mW
Radiation Hardening
No
Reach SVHC Compliant
No
Resistance
10kR
Resistance Tolerance
2%
RoHS Compliant
Yes
Series
4300R
Technology
THICK FILM
Terminal Pitch
2.54mm
Termination
Pin
Thickness
2.16mm
Tolerance
2%
Voltage Rating
100V
DC Rated Voltage
100V
Width
0.085inch
Compliance
RoHS
Compliant
Datasheet
Bourns 4308R-102-103LF Datasheet
Download the complete datasheet for Bourns 4308R-102-103LF to view detailed technical specifications.
