Rotary switch featuring a 2-position, SPDT configuration with a latched mechanical action. Rated for 0.1A and 16VDC, this surface mount component utilizes solder terminals and a rotary actuator. Operating across a temperature range of -55°C to 125°C, it offers a mechanical life of 2000 cycles. The switch has a single deck with a single pole per deck and a non-shorting contact style.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Bourns 7814G-1-023E datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Length | 0mm |
| Actuator Type | Rotary |
| Contact Style | Non-Shorting |
| Current Rating | 100mA |
| Depth | 6.2mm |
| Height | 2.55mm |
| Illumination Type | Illuminated |
| Lead Free | Lead Free |
| Length | 5mm |
| Max Current Rating | 100mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Voltage Rating (AC) | 16V |
| Max Voltage Rating (DC) | 16V |
| Mechanical Life | 2000Cycles |
| Mount | Surface Mount |
| Number of Decks | 1 |
| Number of Poles | 1 |
| Number of Poles per Deck | 1 |
| Number of Positions | 2 |
| Orientation | Straight |
| Package Quantity | 500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 7814 |
| Termination | Gull Wing |
| Throw Configuration | SPDT |
| Voltage Rating | 16V |
| Washable | No |
| Weight | 0.2g |
| RoHS | Compliant |
