General purpose inductor featuring 1µH inductance with a 10% tolerance. This phenolic-core, unshielded component offers a 350mA current rating and a low DC resistance of 1Ω. Designed with axial leads for through-hole mounting, it operates across a wide temperature range of -55°C to 105°C and is RoHS compliant. Key specifications include a 230MHz self-resonant frequency and a Q factor of 25 at 25MHz.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Bourns 8230-20-RC datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Bourns 8230-20-RC technical specifications.
| Package/Case | Axial |
| Contact Plating | Tin |
| Core Material | Phenolic |
| Current Rating | 350mA |
| DC Current | 350mA |
| DC Resistance (DCR) | 1R |
| Diameter | 3.05mm |
| Inductance | 1uH |
| Inductance Tolerance | 10% |
| Lead Diameter | 0.51mm |
| Lead Free | Lead Free |
| Lead Length | 66.5mm |
| Lead/Base Style | Axial |
| Length | 7.62mm |
| Max DC Current | 350mA |
| Max Operating Temperature | 105°C |
| Military Standard | Not |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Package Quantity | 1000 |
| Packaging | Bag |
| Q Factor | 25 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Self Resonant Frequency | 230MHz |
| Series | 8230 |
| Shielding | Unshielded |
| Termination | Axial |
| Test Frequency | 25MHz |
| Tolerance | 10% |
| RoHS | Compliant |
