Surface mount shielded wirewound power inductor with 33µH inductance and 20% tolerance. Features a ferrite core, 600mA current rating, and 190mΩ DC resistance. Operates across a -55°C to 125°C temperature range with a Q factor of 40 at 100kHz. Self-resonant frequency is 20MHz.
Frequency20MHz
PackageNonstandard
Resistance190MR
Current Rating600mA
Quick Jump:
Chat with Datasheet
Sponsored by
Sign in to ask questions about the Bourns SRR6603-330ML datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Technical Specifications
Bourns SRR6603-330ML technical specifications.
General
| Package/Case | Nonstandard |
| Core Material | Ferrite |
| Current Rating | 600mA |
| DC Resistance (DCR) | 190mR |
| Depth | 4.4mm |
| Frequency | 20MHz |
| Height | 3mm |
| Height - Seated (Max) | 0.118inch |
| Inductance | 33uH |
| Inductance Tolerance | 20% |
| Lead Free | Lead Free |
| Length | 6.6mm |
| Material | Steel |
| Max DC Current | 600mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Package Quantity | 600 |
| Packaging | Cut Tape |
| Q Factor | 40 |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Resistance | 190MR |
| RMS Current (Irms) | 600mA |
| RoHS Compliant | Yes |
| Sample Rate (Hz) | 100kHz |
| Saturation Current | 240mA |
| Self Resonant Frequency | 20MHz |
| Series | SRR6603 |
| Shielding | Shielded |
| Termination | SMD/SMT |
| Test Frequency | 100kHz |
| Tolerance | 20% |
| Width | 4.4mm |
Compliance
| RoHS | Compliant |
