The AMMC-5026-W10 is a 35GHz general purpose RF amplifier from Broadcom. It features a 10.5dB gain and operates at a maximum supply voltage of 10V. The amplifier is designed for surface mount applications and has a minimum operating temperature of -55°C. It is lead free and RoHS compliant, making it suitable for a variety of applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Broadcom AMMC-5026-W10 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Bandwidth | 35GHz |
| Package/Case | CHIP |
| Contact Plating | Gold |
| Frequency | 35GHz |
| Gain | 10.5dB |
| Lead Free | Lead Free |
| Max Frequency | 35GHz |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 10V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Operating Frequency | 35 GHz |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Supply Current | 450mA |
| Type | General Purpose |
| RoHS | Compliant |
Download the complete datasheet for Broadcom AMMC-5026-W10 to view detailed technical specifications.
