RF Amplifier, GAAS technology, operating from 6 GHz to 20 GHz with a maximum frequency of 20 GHz. Features 19dB gain, 50 Ohm impedance, and a 5V operating supply voltage. This surface mount die offers a wide bandwidth up to 20 GHz, with a maximum operating temperature of 150°C and a minimum of -55°C. It is lead-free and RoHS compliant, packaged in a tray.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Broadcom AMMC-5620-W10 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Bandwidth | 20GHz |
| Package/Case | CHIP |
| Contact Plating | Gold |
| Frequency | 20GHz |
| Gain | 19dB |
| Height | 0.1mm |
| Impedance | 50R |
| Lead Free | Lead Free |
| Length | 1.41mm |
| Max Frequency | 20GHz |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 1W |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Operating Frequency | 6 GHz to 20 GHZ |
| Operating Supply Current | 95mA |
| Operating Supply Voltage | 5V |
| Package Quantity | 10 |
| Packaging | Tray |
| RoHS Compliant | Yes |
| Supply Current | 107mA |
| Technology | GAAS |
| Test Frequency | 20GHz |
| Width | 1.01mm |
| RoHS | Compliant |
