The CS43122-KSZ is a 24-bit dual analog-to-digital converter (ADC) from Cirrus Logic. It operates at a conversion rate of 192 kilosamples per second and supports SPI and 2-wire interfaces. The device is packaged in a 28-pin SOIC package and is designed for surface mount applications. It is RoHS compliant and operates within a temperature range of -10°C to 70°C. The CS43122-KSZ is suitable for a variety of applications, including data acquisition and industrial control systems.
PackageSOIC
MountingSurface Mount
Quick Jump:
Technical Specifications
Cirrus Logic CS43122-KSZ technical specifications.
General
| Package/Case | SOIC |
| Contact Plating | Tin, Matte |
| Conversion Rate | 192KS/s |
| Interface | SPI, Serial, 2-Wire |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -10°C |
| Max Supply Voltage | 5.75V |
| Min Supply Voltage | 5.25V |
| Mount | Surface Mount |
| Nominal Supply Current | 27mA |
| Number of Bits | 24 |
| Number of Channels | 2 |
| Number of Converters | 2 |
| Number of DAC Channels | 2 |
| Operating Supply Voltage | 5.5V |
| Output Polarity | Bipolar |
| Output Type | Voltage |
| Package Quantity | 27 |
| Packaging | Tray |
| Resolution | 24b |
| RoHS Compliant | Yes |
| Sampling Rate | 192000S/s |
| Supply Type | Analog, Digital |
Compliance
| RoHS | Compliant |
Datasheet
Cirrus Logic CS43122-KSZ Datasheet
Download the complete datasheet for Cirrus Logic CS43122-KSZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
