24-bit, 2-channel stereo digital-to-analog converter (DAC) with a sampling rate of 192 kS/s. Features bipolar voltage output and serial input loading via SPI, I2C, or 3-wire interfaces. Packaged in a 24-pin TSSOP (4.4mm width, 0.9mm height) for surface mounting. Operates with a single supply voltage of 5V (3.14V to 5.25V range) and has a maximum power dissipation of 290mW. RoHS compliant and lead-free.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Cirrus Logic CS4350-CZZ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Cirrus Logic CS4350-CZZ technical specifications.
| Package/Case | TSSOP |
| Contact Plating | Tin, Matte |
| Conversion Rate | 192KS/s |
| Height | 0.9mm |
| Interface | SPI, I2C, Serial, 3-WIRE |
| Lead Free | Lead Free |
| Length | 7.8mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 290mW |
| Max Supply Voltage | 5.25V |
| Min Supply Voltage | 3.14V |
| Mount | Surface Mount |
| Number of Bits | 24 |
| Number of Channels | 2 |
| Number of Converters | 2 |
| Operating Supply Voltage | 5V |
| Output Polarity | Bipolar |
| Output Type | Voltage |
| Package Quantity | 62 |
| Packaging | Rail/Tube |
| Polarity | Bipolar |
| Resolution | 24b |
| RoHS Compliant | Yes |
| Sampling Rate | 192KS/s |
| Supply Type | Single |
| Weight | 0.007478oz |
| Width | 4.4mm |
| RoHS | Compliant |
