LP182M035A1P3

Aluminum Electrolytic Capacitor 1800uF 35V 20% Snap-In 10mm 188mR 1.04A

Aluminum electrolytic capacitor with 1.8mF capacitance and 35V DC rating. Features 20% tolerance, 188mR ESR at 120Hz, and 1.04A ripple current capability. Designed for through-hole PCB mounting with a 10mm lead pitch and 22mm diameter by 25mm height radial package. Operates from -40°C to 105°C with a 1000-hour life expectancy.

PackageRadial

Capacitance1.8mF

Voltage Rating35V

MountingThrough Hole, PCB

Quick Jump:

Technical Specifications

Cornell Dubilier LP182M035A1P3 technical specifications.

General

Capacitance	1.8mF
Package/Case	Radial
Diameter	22mm
Dielectric Material	Aluminium
Dissipation Factor	25%
ESR (Equivalent Series Resistance)	188mR
Height	25mm
Height - Seated (Max)	0.984inch
Lead Diameter	0.8mm
Lead Pitch	10mm
Length	25mm
Life (Hours)	1000Hour
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Mount	Through Hole, PCB
Package Quantity	100
Packaging	Bulk
Reach SVHC Compliant	No
Ripple Current	1.04A
RoHS Compliant	Yes
Series	LP
Termination	Snap in
Test Frequency	120Hz
Tolerance	20%
Voltage Rating	35V
DC Rated Voltage	35V
