Aluminum electrolytic capacitor with 560µF capacitance and 400V DC rated voltage. Features 20% tolerance, 592mΩ ESR at 120Hz, and 2.12A ripple current capability. This radial component has a 35mm diameter and 45mm height, with a 10mm lead pitch for through-hole PCB mounting. Designed for 3000 hours of operation at 105°C, it offers snap-in termination and RoHS compliance.
PackageRadial
Voltage400V
Capacitance560uF
Voltage Rating400V
Quick Jump:
Technical Specifications
Cornell Dubilier SLP561M400H4P3 technical specifications.
General
| Capacitance | 560uF |
| Package/Case | Radial |
| Diameter | 35mm |
| Dielectric Material | Aluminium |
| ESR (Equivalent Series Resistance) | 592mR |
| Height | 45mm |
| Lead Diameter | 1.5mm |
| Lead Length | 6.3mm |
| Lead Pitch | 10mm |
| Length | 45mm |
| Life (Hours) | 3000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole, PCB |
| Package Quantity | 40 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Ripple Current | 2.12A |
| RoHS Compliant | Yes |
| Series | SLP |
| Termination | Snap in |
| Test Frequency | 120Hz |
| Tolerance | 20% |
| Voltage | 400V |
| Voltage Rating | 400V |
| DC Rated Voltage | 400V |
Compliance
| RoHS | Compliant |
