The CSW2425 is a solid state relay with a control voltage of 32V and a maximum output current of 25A. It has a maximum output voltage of 280V and is approved by UL, CSA, and VDE. The relay is mounted via screw terminals and has a package quantity of 20 in bulk packaging. It is compliant with RoHS regulations and has a maximum isolation voltage of 4kV.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom CSW2425 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom CSW2425 technical specifications.
| Approvals | UL, CSA, VDE |
| Control Voltage | 32V |
| Current Rating | 25A |
| Input Current | 10mA |
| Input Type | DC |
| Isolation Voltage-Max | 4kV |
| Lead Free | Lead Free |
| Load Current | 25A |
| Max Output Current | 25A |
| Max Output Voltage | 280V |
| Mount | Panel, Chassis Mount, Screw |
| Output Voltage | 280V |
| Package Quantity | 20 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | CSW |
| Termination | Screw |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 280V |
| RoHS | Compliant |
