AC & DC Output Solid State Relay featuring 1A output current and 140V AC output voltage. This SPST relay accepts 35mA DC input with a 10V control voltage. It offers 3.75kV isolation voltage and is housed in a 16-pin PDIP package for PCB through-hole mounting. Approvals include UL, CSA, and CE, with RoHS compliance.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom DPA4111 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, CE |
| Capacitance | 2pF |
| Package/Case | PDIP |
| Control Voltage | 10V |
| Current Rating | 1A |
| Height | 8.64mm |
| Input Current | 35mA |
| Input Type | DC |
| Isolation Voltage | 3.75kV |
| Isolation Voltage-Max | 3.75kV |
| Lead Free | Lead Free |
| Length | 21.6mm |
| Load Current | 1A |
| Max Input Current | 35mA |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 1A |
| Max Output Voltage | 140V |
| Max Supply Voltage (AC) | 140V |
| Min Supply Voltage (AC) | 20V |
| Max Voltage Rating (AC) | 140V |
| Mount | PCB, Through Hole |
| Output Current | 1A |
| Output Voltage | 140V |
| Package Quantity | 22 |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | DPA |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 140V |
| Width | 7.62mm |
| RoHS | Compliant |
