DC output solid state relay with 30V DC control voltage and 7mA input current. Features 48V DC maximum output voltage and 100mA output current, with a 300mA surge current rating. Module package with DIN rail mounting and screw termination. Operates between -25°C and 60°C with 3.75kV isolation voltage.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom DRA-CN048D24 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom DRA-CN048D24 technical specifications.
| Package/Case | Module |
| Control Voltage | 30V |
| Depth | 6.1mm |
| Height | 92.6mm |
| Input Current | 7mA |
| Input Type | DC |
| Isolation Voltage | 3.75kV |
| Length | 80mm |
| Load Current | 100mA |
| Max Input Voltage | 24V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Max Output Current | 100mA |
| Max Output Voltage | 48V |
| Max Supply Voltage (DC) | 48V |
| Min Supply Voltage (DC) | 0V |
| Max Supply Voltage | 48V |
| Min Supply Voltage | 0V |
| Max Surge Current | 300mA |
| Max Voltage Rating (DC) | 48V |
| Mount | DIN Rail |
| Operating Supply Voltage | 48V |
| Output Current | 100mA |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | DRACN |
| Termination | Screw |
| Throw Configuration | SPST |
| Width | 6.1mm |
| RoHS | Compliant |
Download the complete datasheet for Crydom DRA-CN048D24 to view detailed technical specifications.
