Solid State Relay (SSR) with DC input and AC output. Features a 12V DC control voltage requiring 15mA input current, with a maximum input voltage of 5V. Delivers a 2A AC output current at up to 250V AC, with a maximum surge current of 120A. Offers 2.5kV isolation voltage and operates within a temperature range of -25°C to 60°C. Module package with DIN rail mounting and screw termination.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom DRA-CN240A05 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom DRA-CN240A05 technical specifications.
| Package/Case | Module |
| Control Voltage | 12V |
| Depth | 6.1mm |
| Height | 92.6mm |
| Input Current | 15mA |
| Input Type | DC |
| Isolation Voltage | 2.5kV |
| Length | 80mm |
| Load Current | 2A |
| Max Input Voltage | 5V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Max Output Current | 2A |
| Max Output Voltage | 250V |
| Max Supply Voltage (AC) | 280V |
| Min Supply Voltage (AC) | 24V |
| Max Supply Voltage | 280V |
| Min Supply Voltage | 24V |
| Max Surge Current | 120A |
| Mount | DIN Rail |
| Output Current | 2A |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | DRACN |
| Termination | Screw |
| Throw Configuration | SPST |
| Width | 6.1mm |
| RoHS | Compliant |
