Solid State Relay (SSR) with 5A RMS load current and 380V AC maximum output voltage. Features a 15mA DC control current and 4kV isolation voltage. Designed for DIN rail or panel mounting with screw termination. Operating temperature range from -30°C to 80°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom DRA1-CXE380D5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom DRA1-CXE380D5 technical specifications.
| Package/Case | Module |
| Control Current | 15mA |
| Depth | 10mm |
| Height | 89.6mm |
| Input Current | 15mA |
| Input Type | DC |
| Isolation Voltage | 4kV |
| Length | 89.6mm |
| Load Current | 5A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Output Voltage | 380V |
| Max Supply Voltage (AC) | 380V |
| Min Supply Voltage (AC) | 48V |
| Max Surge Current | 250A |
| Mount | DIN Rail, Panel |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RMS Current (Irms) | 5A |
| Series | DRA |
| Termination | Screw |
| Throw Configuration | SPST |
| Width | 10.03mm |
| RoHS | Compliant |
