Solid State Relay (SSR) with DC input and AC output. Features a 3A load current rating and a maximum output voltage of 280V AC. Operates with a 2.6mA input current and 3mA control current. Offers 4kV isolation voltage and a wide operating temperature range of -40°C to 80°C. Module package mounts via DIN rail with screw termination. RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom DRA1-MP240D3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom DRA1-MP240D3 technical specifications.
| Package/Case | Module |
| Control Current | 3mA |
| Depth | 10mm |
| Height | 89.6mm |
| Input Current | 2.6mA |
| Input Type | DC |
| Isolation Voltage | 4kV |
| Length | 89.6mm |
| Load Current | 3A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 280V |
| Max Supply Voltage (AC) | 280V |
| Min Supply Voltage (AC) | 24V |
| Max Voltage Rating (AC) | 280V |
| Mount | DIN Rail |
| Package Quantity | 10 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | DRA |
| Termination | Screw |
| Throw Configuration | SPST |
| Turn-On Delay Time | 8.33ms |
| Width | 10.03mm |
| RoHS | Compliant |
