Solid State Relay with 5A DC output and 36V AC control input. Features a 48V DC maximum output voltage and 1V DC minimum output voltage, with a 5A load current rating and 60A maximum surge current. This SPST relay offers a 0.6ms turn-on delay and operates within a -30°C to 80°C temperature range. Mounting options include socketable, panel, and DIN rail.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom ED06E5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom ED06E5 technical specifications.
| Package/Case | Module |
| Control Voltage | 36V |
| Current Rating | 5A |
| Depth | 12.7mm |
| Height | 38.4mm |
| Lead Free | Lead Free |
| Length | 29mm |
| Load Current | 5A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Supply Voltage (DC) | 48V |
| Min Supply Voltage (DC) | 1V |
| Max Surge Current | 60A |
| Max Voltage Rating (DC) | 48V |
| Mount | Socketable, Panel, DIN Rail |
| Mounting Style | SOCKET |
| Operating Supply Voltage | 48V |
| Output Voltage | 48V |
| Package Quantity | 10 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | ED |
| Termination | Plug |
| Throw Configuration | SPST |
| Turn-On Delay Time | 0.6ms |
| Weight | 1oz |
| Width | 12.7mm |
| RoHS | Compliant |
