This 125A 530V AC solid state relay from Crydom features a maximum power dissipation of 500mW and is available in a ROHS compliant, plastic package-4. The relay is designed for chassis, panel, or screw mount and has a maximum operating temperature of 80°C and a minimum operating temperature of -40°C. It is UL and CE approved and compliant with RoHS regulations.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom HA48125 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom HA48125 technical specifications.
| Approvals | UL, CE |
| Current Rating | 125A |
| Depth | 58.4mm |
| Height | 23mm |
| Input Current | 10mA |
| Lead Free | Lead Free |
| Length | 45.7mm |
| Load Current | 125A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 125A |
| Max Output Voltage | 530V |
| Max Power Dissipation | 500mW |
| Mount | Chassis, Panel, Screw |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | HA / HD Series |
| Termination | Screw |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 530V |
| Width | 45.7mm |
| RoHS | Compliant |
