AC & DC Output Solid State Relay, featuring a 90A load current capacity and a maximum output voltage of 660V AC. This relay operates with a 32V DC control voltage and a 2mA input current. It offers 4kV isolation voltage and is RoHS compliant. Mounting is via panel or screw, with screw termination. Operating temperature range is -40°C to 80°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom HD6090 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, CSA, VDE, CE |
| Control Voltage | 32V |
| Current Rating | 90A |
| Depth | 45.7mm |
| Height | 23mm |
| Input Current | 2mA |
| Input Type | DC |
| Isolation Voltage | 4kV |
| Isolation Voltage-Max | 4kV |
| Lead Free | Lead Free |
| Length | 58.4mm |
| Load Current | 90A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 90A |
| Max Output Voltage | 660V |
| Mount | Panel, Screw |
| Output Current | 90A |
| Output Voltage | 660V |
| Package Quantity | 10 |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | HA / HD Series |
| Termination | Screw |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 660V |
| Width | 45.7mm |
| RoHS | Compliant |
