AC & DC Output Solid State Relay with a 40A load current rating and 75V DC output voltage. Features a 12mA DC input current and 2.5kV isolation voltage. Operating temperature range from -30°C to 80°C. Surface mountable with screw termination, offering a 150ms turn-on delay.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom LVD75B40 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current Rating | 40A |
| Depth | 19.8mm |
| Height | 22.9mm |
| Input Current | 12mA |
| Input Type | DC |
| Isolation Voltage | 2.5kV |
| Length | 58.4mm |
| Load Current | 40A |
| Max Input Current | 12mA |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 40A |
| Max Output Voltage | 75V |
| Max Supply Voltage | 75V |
| Min Supply Voltage | 3V |
| Max Surge Current | 120A |
| Mount | Surface Mount, Screw |
| Operating Supply Voltage | 75V |
| Output Current | 40A |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | LVD |
| Termination | Screw |
| Throw Configuration | SPST |
| Turn-On Delay Time | 150ms |
| Weight | 3.527396oz |
| Width | 45.7mm |
| RoHS | Compliant |
Download the complete datasheet for Crydom LVD75B40 to view detailed technical specifications.
