The M5060THC1200 is a 60A general purpose rectifier diode module from Crydom, featuring a maximum operating temperature of 125°C and a minimum operating temperature of -40°C. It has a maximum repetitive reverse voltage of 1.2kV and a maximum reverse voltage of 1.2kV. The module is chassis mount with screw and is available in a package quantity of 10. It is RoHS compliant and part of the M50 Diode Series.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom M5060THC1200 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Average Rectified Current | 60A |
| Package/Case | Module |
| Forward Current | 60A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Repetitive Reverse Voltage (Vrrm) | 1.2kV |
| Max Reverse Voltage (DC) | 1.2kV |
| Mount | Chassis Mount, Screw |
| Package Quantity | 10 |
| Packaging | Bulk |
| Peak Non-Repetitive Surge Current | 800A |
| RoHS Compliant | Yes |
| Series | M50 Diode Series |
| RoHS | Compliant |
Download the complete datasheet for Crydom M5060THC1200 to view detailed technical specifications.
