Solid State Relay (SSR) with DC input and DC output, featuring a 5A load current capacity and a maximum output voltage of 60V. This SIP package relay requires a 15mA DC input current and operates within a supply voltage range of 0-60V DC. It offers 2.5kV isolation voltage, 100mR on-state resistance, and a wide operating temperature range from -40°C to 80°C. Designed for through-hole mounting with PC pin termination, this SPST relay is RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom MCMX60D5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIP |
| Input Current | 15mA |
| Input Type | DC |
| Isolation Voltage | 2.5kV |
| Load Current | 5A |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -40°C |
| Max Output Voltage | 60V |
| Max Supply Voltage (DC) | 60V |
| Min Supply Voltage (DC) | 0V |
| Max Supply Voltage | 60V |
| Min Supply Voltage | 0V |
| Max Voltage Rating (DC) | 60V |
| Mount | Through Hole |
| On-State Resistance | 100mR |
| Operating Supply Voltage | 60V |
| Package Quantity | 25 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | MCMX |
| Termination | PC Pin |
| Throw Configuration | SPST |
| RoHS | Compliant |
