AC & DC Output Solid State Relay featuring a 5A load current rating and 280V AC output voltage. This SIP package relay accepts a 32V DC input control voltage and offers 4kV isolation. Designed for PCB mounting via through-hole termination, it operates within a 48V to 530V AC supply voltage range.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom MCXE240D5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIP |
| Control Voltage | 32V |
| Current Rating | 5A |
| Input Type | DC |
| Isolation Voltage-Max | 4kV |
| Lead Free | Lead Free |
| Load Current | 5A |
| Max Output Current | 5A |
| Max Output Voltage | 280V |
| Max Supply Voltage (AC) | 530V |
| Min Supply Voltage (AC) | 48V |
| Max Supply Voltage | 530V |
| Min Supply Voltage | 48V |
| Mount | Through Hole, PCB |
| Operating Supply Voltage | 280V |
| Output Voltage | 280V |
| Package Quantity | 25 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | MCX |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 280V |
| RoHS | Compliant |
