The PF240A25R is a solid state relay with a load current of 25A and output current of 10A. It features a single pole single throw configuration and is designed for AC input. The relay is lead free and RoHS compliant, making it suitable for a variety of applications. It is packaged in a SIP package and is available in quantities of 20. The PF240A25R is a through hole mount device with a height of 34.3mm, length of 38.1mm, and width of 22.8mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Crydom PF240A25R datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Crydom PF240A25R technical specifications.
| Package/Case | SIP |
| Height | 34.3mm |
| Input Type | AC |
| Lead Free | Lead Free |
| Length | 38.1mm |
| Load Current | 25A |
| Mount | Through Hole |
| Output Current | 10A |
| Package Quantity | 20 |
| Packaging | Bulk |
| Relay Type | Relay |
| RoHS Compliant | Yes |
| Series | PF, PowerFin™ |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Width | 22.8mm |
| RoHS | Compliant |
