Board mount DC/DC converter delivering 20W output power with a 12Vdc output voltage and 1.67A maximum output current. Features a wide 9-36Vdc input range and 85% efficiency. Includes UVLO, OVP, OCP, and SCP protection. Isolated design with 1.5kV isolation voltage. Operates from -40°C to 85°C in a DIP package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the CUI PYB20-Q24-S12 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | DIP |
| Current - Output 1 | 1.667A |
| Efficiency | 89% |
| Features | UVLO, OVP, OCP, SCP |
| Height | 0.47inch |
| Isolation | Isolated |
| Isolation Voltage | 1.5kV |
| Lead Free | Lead Free |
| Length | 2inch |
| Max Input Voltage | 36V |
| Min Input Voltage | 9V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 1.667A |
| Max Power Dissipation | 20W |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Power | 20W |
| Output Voltage | 12V |
| Package Quantity | 19 |
| Packaging | Rail/Tube |
| RoHS Compliant | Yes |
| Series | PYB20 |
| Voltage - Output 1 | 12V |
| Weight | 1oz |
| Width | 1inch |
| RoHS | Compliant |
