Board mount DC/DC converter providing a regulated 9Vdc output at 500mA, with a maximum output power of 4.5W. Features include over-temperature protection (OTP) and short-circuit protection (SCP), operating within an input voltage range of 11Vdc to 32Vdc. This non-isolated regulator boasts up to 95% efficiency and is housed in a SIP package suitable for through-hole mounting. It operates across a wide temperature range from -40°C to 85°C and is RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the CUI V7809-500 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIP |
| Current - Output 1 | 500mA |
| Efficiency | 95% |
| Features | OTP, SCP |
| Height | 0.4inch |
| Isolation | Non-Isolated |
| Lead Free | Lead Free |
| Length | 0.45inch |
| Max Input Voltage | 32V |
| Min Input Voltage | 11V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 500mA |
| Max Power Dissipation | 4.5W |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Power | 4.5W |
| Output Voltage | 9V |
| Package Quantity | 43 |
| Packaging | Rail/Tube |
| RoHS Compliant | Yes |
| Series | V78-500 |
| Voltage - Output 1 | 9V |
| Width | 0.3inch |
| RoHS | Compliant |
