Board mount DC/DC converter with 5V, 200mA output, delivering 1W of power. Features a 10.8-13.2 Vdc input range, 6kV isolation voltage, and 75% efficiency. Operates across a -40°C to 85°C temperature range and includes short circuit protection. Packaged in a SIP case for through-hole mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the CUI VHS1-S12-S5-SIP datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIP |
| Current - Output 1 | 200mA |
| Efficiency | 75% |
| Features | SCP |
| Height | 0.49inch |
| Isolation Voltage | 6kV |
| Lead Free | Lead Free |
| Length | 0.77inch |
| Max Input Voltage | 13.2V |
| Min Input Voltage | 10.8V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 200mA |
| Max Power Dissipation | 1W |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Power | 1W |
| Output Voltage | 5V |
| Package Quantity | 25 |
| RoHS Compliant | Yes |
| Series | VHS1-SIP |
| Voltage - Output 1 | 5V |
| Weight | 0.148151oz |
| Width | 0.39inch |
| RoHS | Compliant |
