1W isolated DC/DC converter with 12V output voltage and 83mA output current. Features a 4.75-5.25Vdc input range, 71% efficiency, and DIP package for through-hole mounting. Operates across a -40°C to 85°C temperature range with 1kV isolation voltage and short-circuit protection.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the CUI VIBLSD1-S5-S12-DIP datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | DIP |
| Current - Output 1 | 83mA |
| Efficiency | 71% |
| Features | SCP |
| Height | 7mm |
| Isolation | Isolated |
| Isolation Voltage | 1kV |
| Lead Free | Lead Free |
| Length | 20mm |
| Max Input Voltage | 5.25V |
| Min Input Voltage | 4.75V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 83mA |
| Max Power Dissipation | 1W |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Power | 1W |
| Output Voltage | 12V |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| RoHS Compliant | Yes |
| Series | VIBLSD1-DIP (1W) |
| Voltage - Output 1 | 12V |
| Weight | 0.084658oz |
| Width | 10mm |
| RoHS | Compliant |
