The CUI VSK-S3-9U DC/DC converter is a 3W board mount module with a single 9V output capable of delivering up to 330mA. It operates within a temperature range of -25°C to 70°C and features overvoltage protection, overtemperature protection, and short circuit protection. The module is lead free and RoHS compliant, and is packaged in a through hole package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the CUI VSK-S3-9U datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current - Output 1 | 330mA |
| Efficiency | 74% |
| Features | OVP, OTP, SCP |
| Height | 15mm |
| Lead Free | Lead Free |
| Length | 37mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Output Current | 330mA |
| Max Power Dissipation | 3W |
| Mount | Through Hole |
| Number of Outputs | 1 |
| Output Power | 3W |
| Output Voltage | 9V |
| Package Quantity | 13 |
| RoHS Compliant | Yes |
| Series | VSK-S3 (3W) |
| Voltage - Output 1 | 9V |
| Weight | 0.056lb |
| Width | 23mm |
| RoHS | Compliant |
